Typically the base which is bolted into a huge concrete pad provides the essential support for a tower crane. The base is connected to a tower or a mast and stabilizes the crane which is attached to the inside of the structure of the building. Often, this attachment point is to a concrete lift or to an elevator shaft.
Usually, the mast is a triangulated lattice structure measuring 10 feet square or 0.9m2. The slewing unit is connected to the very top of the mast. The slewing unit consists of a gear and a motor which enable the crane to rotate.
Tower cranes may have a max unsupported height of 80m or 265 feet, while the tower crane's maximum lifting capacity is 16,642 kg or 39,690 lbs. with counter weights of 20 tons. In addition, two limit switches are used in order to make sure that the driver does not overload the crane. There is even one more safety feature called a load moment switch to make sure that the operator does not surpass the ton meter load rating. Finally, the maximum reach of a tower crane is 70 meters or 230 feet.
There is definitely a science involved with erecting a tower crane, especially due to their extreme heights. At first, the stationary structure has to be transported to the construction location by utilizing a huge tractor-trailer rig setup. Then, a mobile crane is utilized in order to assemble the equipment part of the crane and the jib. After that, these parts are connected to the mast. Then, the mobile crane adds counterweights. Forklifts and crawler cranes may be a few of the other industrial machines that is utilized to erect a crane.
When the building is erected, mast extensions are added to the crane. This is how the crane's height could match the building's height. The crane crew uses what is called a climbing frame or a top climber that fits between the slewing unit and the top of the mast. A weight is hung on the jib by the work crew in order to balance the counterweight. When complete, the slewing unit is able to detach from the top of the mast. In the top climber, hydraulic rams are used to adjust the slewing unit up an additional 6.1m or 20 feet. After that, the operator of the crane uses the crane to insert and bolt into place another mast part piece.
